IgniteNet ML2.5-60-19 MetroLinq 2.5Gb 19cm

IgniteNet’s™ MetroLinq™ 2.5G 60 is the world’s first cost-effective high capacity 60GHz PTP radio enabling high performance, interference-free connections worldwide. The MetroLinq™ 2.5G 60 has an added advantage of being license-free in most markets globally, allowing ultra fast deployment and without the hassle of other frequency bands requiring a license. The MetroLinq™ also includes a second 5GHz radio which can be configured as PtP (backup) to provide integrated redundancy without and additional hardware or complexity.

• Inteference-Free & Unlicensed Band
• Dual Band 60GHz & 5GHz Operation
• Powerful, Flexible Configuration

KEY FEATURES:

• 2.5+ Gbps Aggregate throughput; dynamically allocated (60GHz)
• Management VLAN support and VLAN pass-through
• Supports Service Provider and Enterprise type networks
• Stand-alone or Cloud-controlled operating modes
• Link failover/backup (60GHz + 5GHz) Per Client
• 128bit AES Encryption (standard; 5GHz, and 60GHz)
• SNMP Monitoring with Private MIB

HARDWARE FEATURES:

• 1x 2.5 Gigabit Ethernet Port (PoE IN 24-48v
• 1x SFP Port
• 1x Screw Terminal Block (DC Power IN 24-48v)
• 1x USB 3.0 Port
• Dual flash image support

LED:

• Power, Ethernet, Wireless, Health/Status

DIMENSIONS (L X W X H ):

• 190 x 190 x 120 mm/ 7.48 x 7.48 x 4.72 inch (ML2.5-60-19)

WEIGHT:

• 1.25 kg/ 2.76 lb without mount (ML2.5-60-19)

POWER:

• 24-48V/1.5A passive Gigabit PoE or DC

OPERATING ENVIRONMENT:

• Operating Temperature: -30C. to 55C.
• Store Temperature: -30C. to 55C.
• Operating Humidity: 10 to 90% non-condensing (RH)

REGULATORY / STANDARDS COMPLIANCE:

• FCC/IC
• CE
